Automatic PET Bottle Filling Machine / Bottling Line / Project

mae peiriant tri-yn-un ar gyfer potel PET yn integreiddio'r swyddogaeth o rinsio, llenwi a chapio gyda'i gilydd. Yn seiliedig ar dechnoleg uwch dramor, ac wedi'i ddylunio yn unol â gofynion prosesu llenwi dŵr

Prif nodweddion

---

1. This machine has a compact structure, completed control system, easy to operate and highly automated.

2. By changing the star-wheel, screw bottle inlet and arc guide plate can realize to change the bottle shape.

3. The parts that direct contact with product are made of food grade stainless steel and no technology corner pockets and easy to clean.

4. By adopting high speed filling valve, the liquid level is precise and no waste. That guarantees the demand of filling technology.

5. The machine adopts high effective cap sorting system and completely self control and protective device.

6. The machine is equipped with perfect overload protective device that can keep the equipment and operator safely.

7. The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.

8. The electric components and pneumatic components are all introduced from world famous brand products.

Swm y sefyllfa weithio	Rinsio 32, llenwi 32, capio 10
Capasiti cynhyrchu	15000BPH (500ml)
Pwysedd ffynhonnell aer	0.7Mpa
Defnydd aer	1.2m3 / mun
Rinsio pwysedd dŵr	0.2-0.25Mpa
Rinsio cynhwysedd dŵr	2.5T / H.
Prif bŵer modur	3.2kW
Cyfanswm pŵer	4.8kw
Dimensiwn	4250X2150X2200mm (L × W × H)
pwysau	5200kg

Rydym hefyd yn darparu'r Offer Potelu Dŵr Pur Awtomatig Cyflawn

Mae'n cynnwys 4 prif ran:

1. Plastic bottle blow molding machine
2. Water cleaning system
3. Water washing, filling, capping machine.
4. Conveyor system, labeling machine, dating machine, film wrapping machine

Prif ddisgrifiad y llinell gyflawn:

---

1. The plant can produce different volume bottles, from 200ml to 2000ml bottles, round and square bottles, plastic and glass bottles. It is very easy to change the different bottle molds.

2. The plant is highly automatic, you can operate on the touch screen to adjust the machine speed and working.

3. We have different speed plants, commonly, 2000BPH, 4000BPH, 7000BPH, 10,000BPH, 15000BPH..ect.

4. The material is stainless steel 304, food grade much clean and safe.

5.  We provide the engineers for customer installation, training in customer's factory.

Modelau a Rhestr Cyflymder

---

Model	XGF8-8-3	XGF14 / 12/5	XGF16 / 16/5	XGF24 / 24/8	XGF32 / 32/10
Golchi dwylo	8	14	16	24	32
Falfiau llenwi	8	12	16	24	32
Capio dwylo	3	5	5	8	10
Poteli PET / Gwydr addas (150ml i 2000ml)
Capasiti (Cyflymder) Sylfaen ar 500ml	2000BPH	5000BPH	7000BPH	12000BPH	15000BPH

Cyflenwr Brandiau Cydrannau Trydan

---

Prif gyfansoddiad	Cyflenwr Disgrifiad
PLC	Mitsubishi (Japan), Siemens (yr Almaen)
Sgrin gyffwrdd	Weinview (Taiwan)
Trawsnewidydd amledd	Mitsubishi (Japan), Siemens (yr Almaen)
Newid aer	Schneider (Ffrainc)
Torwr	Siemens (Yr Almaen)
Cysylltydd	Siemens (Yr Almaen)
Swits ffotodrydanol	Omron (Japan)

Manylion Cyflym

---

Math: Peiriant Llenwi
Cyflwr: Newydd
Cais: Diod, Cemegol, Meddygol
Math o Becynnu: Poteli
Deunydd Pecynnu: Plastig
Gradd Awtomatig: Awtomatig
Math a yrrir: Trydan
Foltedd: 380V / 220V
Pwer: 4.8KW
Man Tarddiad: Shanghai, China (Mainland)
Enw Brand: NPACK
Dimensiwn (L * W * H): 4250X2150X2200mm
Pwysau: 5200KGS
Ardystiad: CE, ISO, SGS
Gwasanaeth Ôl-werthu a Ddarperir: Peirianwyr ar gael i wasanaethu peiriannau dramor
Ffatri: PEIRIANNAU CYSYLLTIADAU
Maint y Botel: 150ml i 2000ml
Diamedr Gwddf Botel: 15-55mm
Deunydd Botel: Plastig / Gwydr
Cyflymder (sylfaen ar botel 500ml): 15000B / H.
System Reoli: Sgrin Gyffwrdd PLC (MITSUBISHI JAPAN)
Cap: Sgriw / Cap Gwasg
Codwr cap: Wedi
Llenwi Hylif: Dŵr Mwynol / Pur

---
